43
3. Web Control
The Main window as shown above is
displayed at first. However, if you have
enabled User Password on the Tools window
(
48), a dialog prompting you to enter
the password as shown on the right will be
displayed, and no operation is enabled until
you have entered the password. After entering
the preset password, the dialog disappears
and the Main window will be displayed.
As shown below, you can open a window by
clicking the corresponding tab at the top right
of the window.
3.2 Crestron e-Control
®
User Password dialog
Tab
Tab Description
Logout
Logs out from e-Control
®
.
This tab appears only when User Password of the Tools window is
enabled.
Tools Opens Tools window. (
47)
Info Opens Info window. (
49)
Contact IT Help Opens Help Desk window. (
50)
To Next Page
