Hitachi CP-X2011N Service Manual

2
CP-X2511N(C15I-25N2) / CP-X3011N(C15I-30N2) / CP-X4011N(C15I-40N2) / CP-X2011N(C15-20N2) / ED-X45N(C15-20N2)
1. Features
• High Brightness • Rich Connectivity
• Low Noise • Powerful Sound
2. Specifications
Liquid
crystal
panel
Drive system TFT active matrix
Panel size 1.6cm(0.63 type)
Number of pixels 1024 (H) x 768 (V)
Lamp
210W UHP (CP-X2511N / CP-X3011N / CP-X4011N)
190W UHP (CP-X2011N / ED-X45N)
Digital
signal
HDMI
Type:T.M.D.S
Signal level : DC : 3.3V±5%
AC : 0.15-1.56Vp-p
Computer
signal
Computer IN
1 Video : Analog 0.7Vp-p(75Ω termination)
H/V. sync. : TTL level (positive/negative)
Composite sync. : TTL level
2
Computer OUT
Video:Analog 0.7Vp-p, 75Ω output impedance (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
VIDEO
signal
VIDEO IN 1.0Vp-p (75Ω termination)
S-VIDEO IN
Y signal: 1.0±0.1Vp-p, (75Ω termination)
C signal: 0.286±0.1Vp-p (NTSC burst signal, 75Ω termination)
0.3±0.1Vp-p (PAL/SECAM burst signal, 75Ω termination)
COMPONENT
VIDEO
Y 1.0±0.1Vp-p, 75Ω termination (positive)
C
B
/P
B
0.7±0.1Vp-p, 75Ω termination (positive)
C
R
/P
R
0.7±0.1Vp-p, 75Ω termination (positive)
AUDIO
signal
MIC IN -30~-60dB(1~30mVrms)
AUDIO IN 1
200mVrms, 47kΩ or more (max. 2Vrms)
AUDIO IN 2
AUDIO IN 3 L/R 200mVrms, 47kΩ or more (max. 2Vrms)
HDMI
Linear PCM format
Sampling frequency : 48kHz, 44.1kHz, 32kHz
AUDIO OUT output impedance 1kΩ (max. 2Vrms)
RS232C
INPUT Hi: Max. 20V, Min. 2.6V Lo: Typ. –20.0V, Max. 0.8V
OUTPUT Hi: Typ. 8.0V, Min. 5.0V Lo: Typ. –7.0V, Max. –5.0V
USB
Type-A
(Storage)
I/O Level
(differential)
Amplitude of
differential signal
|(D+)-(D-)|>0.2V
D+>2.8V, D-<0.3V or D+>2.8V,D-<0.3V
Amplitude of
signal
INPUT: “L”

0.8V or less, “H” 2.0V or more
OUTPUT: “L” 0.3V or less, “H” 2.8V
~
3.45V
Type-B
(Mouse,
Display)
I/O Level
(differential)
Amplitude of
differential signal
|(D+)-(D-)|>0.2V
D+>2.8V, D-<0.3V or D+>2.8V,D-<0.3V
Amplitude of
signal
INPUT: “L” 0.8V or less, “H” 2.0V or more
OUTPUT: “L” 0.3V or less, “H” 2.8V
~
3.6V
NETWORK 100Base-TX / 10Base-T Differential output : 1.9 ~ 2.1V (100Ω termination)
Speaker 8W x 2 (mono)
Power supply
AC100~120V/3.4A, AC220~240V/1.8A (CP-X2511N / CP-X3011N / CP-X4011N)
AC100~120V/3.2A, AC220~240V/1.7A (CP-X2011N / ED-X45N)
Power consumption
AC100~120V/330W, AC220~240V/310W (CP-X2511N / CP-X3011N / CP-X4011N)
AC100~120V/310W, AC220~240V/290W (CP-X2011N / ED-X45N)
Dimensions 317 (W) x 98 (H) x 288 (D) mm (Not including protruding parts)
Weight approx. 3.5kg
Temperature range Operation : 5~35°C Storage : -20~60°C
Accessories
Remote control x1
Computer cable x 1
Power cord x 1
Battery x 2
User’s manual x 1
Lens cap x 1
