3. Web Control
3.2 Crestron e-Control
®
(continued)
3.2.1 Main window
You can operate the basic controls of the projector on this screen.
• If the projector is in the standby mode, only the Power button can be
operated.
NOTE
1 Click a button and operate as follows.
Button Description
Power Turns the power on/off.
Vol -/ Vol + Adjusts the volume setting.
Mute Turns Mute on/off.
2 Sources List
You can click a button to switch the input channel. The cursor will move according
to the currently selected input port.
Button Description
Computer in1 Selects input from COMPUTER IN1 port.
Computer in2 Selects input from COMPUTER IN2 port.
LAN Selects input from LAN port.
USB Type A Selects input from USB TYPE A port.
USB Type B Selects input from USB TYPE B port.
HDMI Selects input from HDMI port.
Component Selects input from COMPONENT port.
S-Video Selects input from S-VIDEO port.
Video Selects input from VIDEO port.
1
4
2
3
