11
When the projector connects network, the projector can be controlled with RS-
232C commands from the computer with web browser.
For details of RS-232C commands, refer to RS-232C Communication / Network
command table
(17).
Command Control via the Network
LAN cable (CAT-5 or greater)
LAN
LAN
Connection
1.
Turn off the projector and the computer.
2.
If you use wired LAN, connect the projector's LAN port to the computer's
LAN port with a LAN cable. Use the cable that fulfills the specification shown
in figure. If you use wireless LAN, insert the USB wireless adapter into the
projector's USB TYPE A port.
3.
Turn the computer on, and after the computer has started up turn the
projector on.
NOTE • If data is transferred via wireless and wired LAN at the same time,
the projector may not be able to process the data correctly.
Command Control via the Network
To Next Page
