Service information
RS-232C(9pin D-sub male:RDED-9P-LNA(4-40)(55))
Plug CU mainframe
51
6 9
*RTS:Request To Send
*CTS:Clear To Send
WFM CONTROL (15pin female:YKF42-8043N)
Plug CU mainframe
Pin
Signal
1 NC
2 RX_232C (IN)
3 TX_232C (OUT)
4 NC
5 GND
6 NC
7 RTS (OUT)
8 CTS (IN)
9 NC
Pin
1
2
3
4
5
6
7
8
9
Pin
Signal
1
2 WFM CTL0
3 WFM CTL1
4 WFM CTL2
5 WFM CTL3
6 WFM CTL4
7 WFM CTL5
8 WFM CTL6
9 WFM CTL7
10
11
12
13
14
15 SHIELD
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
MODE
Analog
PIX
OUT
Analog
WFM
OUT
CTL0
CTL1
CTL2
CTL3
CTL4
CTL5
CTL6
CTL7
R R R Lo
Hi Hi Hi Hi Hi Hi Hi
G G G Hi Lo
Hi Hi Hi Hi Hi Hi
B B B Hi Hi Lo
Hi Hi Hi Hi Hi
ENC ENC
ENC
Hi Hi Hi Lo
Hi Hi Hi Hi
SUP ENC
SUP Hi Hi Hi Hi Lo
Hi Hi Hi
SEQ ENC
SUP Hi Hi Hi Hi Hi Lo
Hi Hi
