Specifications
Power supply voltage CU-HD500J AC100V 50/60Hz
CU-HD500U AC117V 60Hz
CU-HD500E AC230V 50Hz
Power consumption 300W approx. (AC operation, including Z-HD5000 or SK-HD1000,VF-402 and
AUX POWEROUT 100VA)
Ambient Temperature Operating: 0 to +40
℃
Storage: -20 to +60
℃
Dimensions 433(W)88(H)330(D)mm
Mass 9.5kg approx.
Max. Cable length
1km
■Input output signals (CU-HD500)
Input signals
GEN LOCK IN
B-BST 0.45Vp-p/75Ω(loop through)
HDTV tri-level sync 0.60Vp-p/75Ω
(loop through)
BNC
DIGITAL RET IN1/2 HD SDI(1080i,720p) or SD SDI
*HD SDI input is same as output format
・1080i : SMPTE274M
・SD-SDI : SMPTE259M-C
BNC
PROMPT IN
VS or VBS 1.0Vp-p/75Ω(loop through)
BNC
INTERCOM(HEAD SET) -60dBm XLR-5pin(Female)
COMMUNICATION D-sub 15pin
・INTERCOM 0dBm , 600Ωat 4Wire
0dBu or -15dBu ,200Ωat 2Wire
・PGM 0dBm/600Ω
・R/G TALLY
Voltage or contact supply
REMOTE 1 1.5Vp-p 4pin
REMOTE 2 1.5Vp-p 4pin
RS-232C 9600 baud D-sub 9pin
