Specifications
Output signals
DIGITAL OUT HD-SDI(1080i)
(Embedded audio available)
・1080i:SMPTE274M 0.8Vp-p/1.5Gbps
BNC (x2)
HD-SDI(1080i) or SD-SDI selectable
(Embedded audio available)
・1080i :SMPTE274M 0.8Vp-p/1.5Gbps
・SD-SDI:SMPTE259M-C 0.8Vp-p/270Mbps
BNC (x4 (x2+x2))
HD-SDI(1080i) or SD-SDI selectable PIX
(Embedded audio available)
・1080i :SMPTE274M 0.8Vp-p/1.5Gbps
・SD-SDI:SMPTE259M-C 0.8Vp-p/270Mbps
BNC (x1)
MIC OUT 1
0dBm/600Ω
XLR-3pin
MIC OUT 2
0dBm/600Ω
XLR-3pin
INTERCOM (HEAD SET) 0dBu MAX+15dB XLR-5pin(Female)
Remote 1 1.5Vp-p 4pin
Remote 2 1.5Vp-p 4pin
RS-232C 9600 baud D-Sub 9 pin
COMMUNICATION D-sub 25pin
・INTERCOM 0dBm , 600Ωat 4Wire
0dBu or -15dBu ,200Ωat 2Wire
TALLY OUT(R,G) Contact D-sub 9pin
WFM CONTROL WFM 0-7 0/5V D-sub 15pin
MIC Remote MIC1/2 Gain D-sub 15pin
