K6602705
Rev.3
08.20.01
- 43 -
Table 6.5 Identify Device Information (
Continued)
Word Description Value
(HEX.)
91 Current advanced power management level value
Word 91 contains the current Advanced Power Management level settings.
40XXh
92 Master password revision code
Word 92 contains the value of the Master password revision code set when the
Master Password was last changed.
XXXXh
93 Hardware reset result
Bit 15 0 (fixed)
Bit 14 1 (fixed)
Bit 13 1 = Device detected CBLID- above V
iH
0 = Device detected CBLID- below V
iL
Bit 12 - 8 Device 1 hardware reset result. Device 1 clears these bits to zero.
Device 1 sets these bits as follows:
Bit 12 0 = Reserved
Bit 11 1 = Device 1 asserted PDIAG-
Bit 10 - 9 These bits indicate how Device 1 determined the
device number:
00, 11 = Reserved
01 = A jumper was used
10 = the CSEL signal was used
Bit 8 1 (fixed)
Bit 7 - 0 Device 0 hardware reset result. Device 1 clears these bits to zero.
Device 0 sets these bits as follows:
Bit 7 0 = Reserved
Bit 6 1 = Device 0 responds when Device 1 is selected
Bit 5 1 = Device 0 detected the assertion of DASP-
Bit 4 1 = Device 0 detected the assertion of PDIAG0
Bit 3 1 = Device 0 passed diagnostic
Bit 2 - 1 These bits indicate how Device 0 determined the
device number:
00, 11 = Reserved
01 = A jumper was used
10 = the CSEL signal was used
Bit 0 1 (fixed)
XXXXh
94-126 Reserved 0000h
