Hitachi G400 - Americas Single-Phase PDU 1 P30 A-8 C13-3 C19 UL.P; Americas Single-Phase PDU 1 P30 A-15 C13-3 C19 UL.P

Americas single-phase PDU 1P30A-8C13-3C19UL.P
The following figure and table describes the specifications of the PDU.
Figure 1 Americas PDU for the Hitachi Universal V2 Rack (Single-phase
PDU 1P30A-8C13-3C19UL.P)
Part Number
Region Phase Description
1P30A-8C13-3C19UL.P Americas Single
• 208V, 30A (24A
rated) 60Hz
• 8 IEC C13 + 3 IEC
C19 sockets
• NEMA L6-30P input
power plug
• 4.5 m (14.76 feet)
cable
Americas single-phase PDU 1P30A-15C13-3C19UL.P
The following figure and table describes the specifications of the PDU.
Figure 2 Americas PDU for the Hitachi Universal V2 Rack (Single-phase
PDU 1P30A-15C13-3C19UL.P)
Part Number
Region Phase Description
1P30A-15C13-3C19UL.
P
Americas Single
• 208V, 30A (24A
rated) 60Hz
110 Hitachi Universal V2 Rack power distribution units
Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide
