Hitachi L100 Series Service Manual

1. Pre-Operation Check
Before starting adjustment and maintenance, be sure to check the following specifications of the inverter
and the motor.
1.1 Check Inverter model and Manufacturing number (MFG No).
NE16452-6
MADE IN JAPAN
Hitachi, Ltd.
HITACHI
Model : L100-015NFE
HP/kW : 2 / 1.5
In
p
ut/Entree: 16.0 A1Ph200-240V50
,
60Hz
9.3 A3Ph200-240V50
,
60Hz
Out
p
ut/Sortie: 1-360Hz 7.1 A3Ph200-240V
MFG No. 78H T1129670060
Date: 9708
You can find these information from the specification label which attached at the side cover of the unit.
(1) Description of the model name.
(2) Description of MFG No.
Inverter model
MFG No.
T112967 0060H87
Unique number
Production code
Revision of the inverter
Production Month
(1 - 9, 0:October, J:November, K:December)
Production year
(The unit digit of the year of grace. 7:1997, 8:1998, 9:1999, 0:2000)
1-1
EF015 HL100
Version number
E: European version
U: US version
R: Japanese versionSeries name
Structure type
F: With operator
Input voltage class
005
004
: 7.5kW
: 5.5kW
: 4.0kW
: 3.7kW
: 3.0kW
: 2.2kW
: 1.5kW
: 1.1kW
: 0.75kW
: 0.55kW
: 0.4kW
: 0.2kW002
Applicable motor kW
L: 3 phase 200V class
N: Single/3 phase 200V class
H: 3 phase 400V class
075
055
040
037
030
022
015
011
007
M: Single phase 100V class
