1.2 Check Inverter parameter and motor specification.

[1] Inverter specifications.

(1) Inverter specifications (Monitor mode)

Display Function name Category Screen display Initial Remarks

order Code display EU US JPN

1 Output frequency monitor Monitor d01 - - -

2 Output current monitor Monitor d02 - - -

3 Running direction monitor Monitor d03 - - -

4 Feedback data of PID

control monitor

Monitor d04 - - -

5 Intelligent input terminal

condition monitor

Monitor d05 - - -

6 Intelligent output terminal

condition monitor

Monitor d06 - - -

7 Output frequency

converted value monitor

Monitor d07 - - -

8 Trip monitor Monitor d08 - - -

9 Trip history monitor Monitor d09 - - -

(2) Inverter specifications (Basic function mode)

Display Function name Category Screen display Initial Remarks

order Code display EU US JPN

1 Output frequency setting set F01 0.0 0.0 0.0

2 Acceleration time 1 set F02 10 10 10

3 Deceleration time 1 set F03 10 10 10

4 Running direction setting set F04 00 00 00

5 Extended function

A group setting

set A--

6 Extended function

B group setting

set B--

7 Extended function

C group setting

set C--

1-2

Hitachi L100 Series Service Manual
