Hitachi L100 Series Service Manual

(3) Inverter specifications (Extended function mode : A group)
Display Function name Category Screen display Initial Remarks
order Code display EU US JPN
1 Frequency destination set
A01
01 01 00
2 Running command
destination
set
A02
01 01 02
3 Base frequency set
A03
50 60 60
4 Maximum frequency set
A04
50 60 60
5 External frequency setting
start
set
A11
000
6 External frequency setting
end
set
A12
000
7 External frequency setting
start rate
set
A13
000
8 External frequency setting
end rate
set
A14
100 100 100
9 External frequency start
pattern
set
A15
01 01 01
10 Time constant of the filter
of analog input
set
A16
888
11 Multi-speed 1 to 16 set
A20 - A35
0 0 Note 1
12 Jogging frequency set
A38
1.0 1.0 1.0
13 Stop mode of jogging set
A39
00 00 00
14 Torque boost mode set
A41
00 00 00
15 Level of
manual torque boost
set
A42
11 11 11
16 Manual torque boost
frequency
set
A43
10.0 10.0 10.0
17 V/f characteristics set
A44
00 00 00
18 V-gain set
A45
100 100 100
19 Selection of DC braking set
A51
00 00 00
20 DC braking frequency set
A52
0.5 0.5 0.5
21 DC braking waiting time set
A53
0.0 0.0 0.0
22 DC braking force set
A54
000
23 DC braking time set
A55
0.0 0.0 0.0
24 Frequency upper limiter set
A61
0.0 0.0 0.0
25 Frequency lower limiter set
A62
0.0 0.0 0.0
26 Jump frequency 1-3 set
A63, A65, A67
0.0 0.0 0.0
27 Jump frequency width 1-3 set
A64, A66, A68
0.5 0.5 0.5
28 Selection of PID control set
A71
00 00 00
29 P gain set
A72
1.0 1.0 1.0
30 I gain set
A73
1.0 1.0 1.0
31 D gain set
A74
0.0 0.0 0.0
32 Scale conversion of
PID control
set
A75
1.0 1.0 1.0
33 Feedback destination set
A76
00 00 00
34 Selection of AVR function set
A81
02 02 02
35 AVR voltage set
A82
230/400 230/460 200/400
36 Second acceleration time set
A92
15.0 15.0 15.0
37 Second deceleration time set
A93
15.0 15.0 15.0
38 Method to use 2nd
acceleration / deceleration
(Acc2 / Dec2)
set
A94
00 00 00
39 Acc1 to Acc2 changing
frequency
set
A95
0.0 0.0 0.0
40 Dec1 to Dec2 changing
frequency
set
A96
0.0 0.0 0.0
41 Acceleration characteristic set
A97
00 00 00
42 Deceleration characteristic set
A98
00 00 00
Note 1 A20;0, A21;5, A22;10, A23;15,A24;20, A25;30, A26;40, A27;50, A28; 60,A29--A35;0
1-3
