Hitachi L100 Series Service Manual

(4) Inverter specifications (Extended function mode : B group)
Display Function name Category Screen display Initial Remarks
order Code display EU US JPN
1 Selection of restart mode set b01 00 00 00
2 Allowable UV time set b02 1.0 1.0 1.0
3 Retry waiting time set b03 1.0 1.0 1.0
5 Electronic thermal level set b12 note note note Rated current of
each inverter
6 Electronic thermal
characteristics
set b13 01 01 00
7 Overload restriction
operation mode
set b21 01 01 01
8 Overload restriction level set b22 note note note Rated current
* 1.25 for each
inverter
9 Deceleration rate while
overload restriction
set b23 1.0 1.0 1.0
10 Selection of software lock set b31 01 01 01
11 Reactive current setting set B32 note note Note Rated current
*0.58 for each
inverter
13 Analog meter adjustment set b81 80 80 80
14 Start frequency adjustment set b82 0.5 0.5 0.5
15 Carrier frequency set b83 5 5 12
16 Data initialization or
Trip history clear
set b84 00 00 00
17 Initialization mode set b85 01 02 00
18 Frequency converting
value
set b86 1.0 1.0 1.0
19 STOP key condition set b87 00 00 00
20 Restart mode after FRS
invalid
set b88 00 00 00
21 Monitor contents
for OPE-J
set b89 01 01 01
