Hitachi L200 Series Quick Reference Guide

1
Caution: Be sure to read the L200 Inverter Manual and follow
its Cautions and Warnings for the initial product installation.
This Quick Reference Guide is intended for reference use by
experienced users in servicing existing installations.
Power Circuit Terminals
Inverter models L200–002NFEF/NFU, –004NFEF/NFU,
–005NFEF
Jumper
+1 + –
U/T1
V/T2
W/T3
Chassis
Ground
Inverter models L200–007NFEF/NFU to –022NFEF/NFU,
–037LFU, –004HFEF/HFU to –040HFEF/HFU
Inverter models –055LFU, –075LFU, –055HFEF/HFU,
–075HFEF/HFU
L1 L2 N/L3
Jumper
+ – +1
Chassis
Ground
U/T1L1 L2 L3 V/T2 W/T3
Jumper
+ –
U/T1 V/T2 W/T3
Chassis
Ground
+1
L1 L2 N/L3
L1 L2 L3
NFEF, NFU
LFU, HFEF,
HFU
U/T1 V/T2 W/T3

Hitachi L200 Series Specifications

General

Output Frequency	0.1-400Hz
Communication	RS-485 (Modbus RTU)
Frequency Range	0.1-400Hz
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Input Voltage	200-240V
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Output Voltage	3-phase, 0 to input voltage
Cooling Method	Forced air cooling
Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000m without derating
Braking Unit	Built-in braking transistor (for models up to 7.5kW), External braking resistor can be connected
