ModBus Data Listing
ModBus Coil List
The following tables list the primary coils for the inverter interface to the network. The
table legend is given below.
• Coil Number - The network register address offset for the coil, in hex and decimal.
Actual network address is 30001 + offset. The coil data is a single bit (binary) value.
• Name - The functional name of the coil
• R/W - The read-only (R) or read-write (R/W) access permitted to the inverter data
• Description - The meaning of each of the states of the coils
List of Coil Numbers
Coil Number Name R/W Description
hex dec.
0000h 00000 (Reserved) R —
0001h 00001 Run command R/W 0 .... Stop
1 .... Run (enabled when A003=03)
0002h 00002 FW/REV command R/W 0 .... REV
1 .... FW (enabled when A003=03)
0003h 00003 External trip (EXT) R/W 0 .... No trip event
1 .... Trip occurred
0004h 00004 Trip reset (RS) R/W 0 .... No reset condition
1 .... Reset
0005h 00005 (Reserved) R —
0006h 00006 (Reserved) R —
0007h 00007 Intelligent input terminal 1 R/W 0 .... OFF *1
1 .... ON
0008h 00008 Intelligent input terminal 2 R/W
0009h 00009 Intelligent input terminal 3 R/W
000Ah 00010 Intelligent input terminal 4 R/W
000Bh 00011 Intelligent input terminal 5 R/W
000Dh 00013 (Not used) — —
000Eh 00014 Run/Stop status R 0 .... Stop (corresponds to D003
monitor)
1 .... Run
000Fh 00015 FW/REV status R 0 .... FW
1 .... RV
0010h 00016 Inverter ready R 0 .... Not ready
1 .... Ready
0011h 00017 (Reserved) R —
0012h 00018 (Reserved) R —
