L2002 Inverter
Inverter Mounting
and Installation
2–11
Check Inverter Dimensions
Step 4: Locate the applicable drawing on the following pages for your inverter.
Dimensions are given in millimeters (inches) format.
NOTE: Some inverter housings require two mounting screws, while others require four.
Be sure to use lock washers or other means to ensure screws do not loosen due to
vibration.
4
5(0.20)
6(0.24)
110(4.48)
H=120(4.90) H=140(5.51)
2.6(0.102)
D=107(4.21) D=130(5.12)
93(3.66)
93(3.66)
107(4.21)
107(4.21)
130(5.12)
120(4.90)
140(5.51)
120(4.90)
140(5.51)
140(5.51)
-002NFU
-002NFEF2
-004NFU2
-004NFEF2
-005NFEF2
HModel D
67(2.64)
80(3.15)
5(0.20)
7(0.16)
D=93(3.66)
2
L200–002NFU2, -002NFEF2, –004NFU2, -004NFEF2, –005NFEF2
