L2002 Inverter
Appendix B
B–23
Note 1: Assume that the inverter current rating is 1000 (for D002).
The following table lists holding registers for the “D” Group Monitor Functions.
D080 Trip counter R Number of trip events,
range is 0 to 65535
0011h 00024 0 to
65535
1 trip
event
List of Holding Registers
Func.
Code
Name R/W Description
Network Data
Reg.ister
Range Res.
hex dec.
Holding Registers, “D” Group Monitor Functions
Func.
Code
Name R/W Description
Network Data
Register
Res.
hex dec.
D081 Trip monitor 1
R Trip monitor 1: factor code 0012h 00018 —
R Frequency 0014h 00020 0.1 Hz
R Current 0016h 00022 0.1 %
R Voltage 0017h 00023 0.1 V
R Run time (high) 0018h 00024 1. h
R Run time (low) 0019h 00025
R ON time (high) 001Ah 00026 1. h
R ON time (low) 001Bh 00027
D082 Trip monitor 2
R Trip monitor 1: factor code 001Ch 00028 —
R Frequency 001Eh 00030 0.1 Hz
R Current 0020h 00032 0.1 %
R Voltage 0021h 00033 0.1 V
R Run time (high) 0022h 00034 1. h
R Run time (low) 0023h 00035
R ON time (high) 0024h 00036 1. h
R ON time (low) 0025h 00037
