L2002 Inverter
Appendix B
B–27
A014 O–L input active range
end voltage
R/W The ending point (offset) for
the active analog input range,
range is 0. to 100.
1024h 04132 0 to 100 1 %
A015 O–L input start
frequency enable
R/W Two options; select codes:
00... Use offset (A011 value)
01... Use 0 Hz
1025h 04133 0, 1 —
A016 External frequency
filter time constant
R/W Range n = 1 to 16, where n =
number of samples for avg.
Set = 17 to use 16-sample avg.
1026h 04134 1 to 17 1
sample
A020 Multi-speed 0 setting R/W Defines the first speed of a
multi-speed profile, range is
0.0 / start frequency to 400 Hz
A020 = Speed 0 (1st motor)
1029h 04137 0 / start
freq. to
4000
0.1 Hz
A220 Multi-speed 0 setting,
2nd motor
R/W Defines the first speed of a
multi-speed profile, range is
0.0 / start frequency to 400 Hz
A220 = Speed 0 (2nd motor)
150Fh 00059 0 / start
freq. to
4000
0.1 Hz
A021 Multi-speed 1 setting R/W
Defines 15 more speeds,
range is 0.0 / start frequency
to 400 Hz.
A021= Speed 1...
A035 = Speed 15
102Bh 04139 0 / start
freq. to
4000
0.1 Hz
A022 Multi-speed 2 setting R/W 102Dh 04141
A023 Multi-speed 3 setting R/W 102Fh 04143
A024 Multi-speed 4 setting R/W 1031h 04145
A025 Multi-speed 5 setting R/W 1033h 04147
A026 Multi-speed 6 setting R/W 1035h 04149
A027 Multi-speed 7 setting R/W 1037h 04151
A028 Multi-speed 8 setting R/W 1039h 04153
A029 Multi-speed 9 setting R/W 103Bh 04155
A030 Multi-speed 10 setting R/W 103Dh 04157
A031 Multi-speed 11 setting R/W 103Fh 04159
A032 Multi-speed 12 setting R/W 1041h 04161
A033 Multi-speed 13 setting R/W 1043h 04163
A034 Multi-speed 14 setting R/W 1045h 04165
A035 Multi-speed 15 setting R/W 1047h 04167
A038 Jog frequency setting R/W Defines limited speed for jog,
range is 0.00 / start frequency
to 9.99 Hz
1048h 04168 0 / start
freq. to
999
0.01 Hz
Holding Registers for “A” Group Standard Functions
Func.
Code
Name R/W Description
Network Data
Register
Range Res.
hex dec.
