34
Analog Output Function Listing
The following table shows all seven functions available for assignment to
the three analog output terminals:
• Terminal [FM], option set by C027
• Terminal [AM], option set by C028
• Terminal [AMI], option set by C029
Option
Code
Function
Name
Description
Corresponding
Signal Range
00 Output
frequency
Actual motor speed,
represented by PWM
signal
0 to max. frequency in Hz
01 Output current Motor current (% of
maximum rated output
current), represented by
PWM signal
0 to 200%
03 Digital output
frequency
Output frequency (avail-
able only at FM output)
0 to max. frequency in Hz
04 Output voltage Rated output voltage to
motor
0 to 100%
05 Input power Rated input power 0 to 200%
06 Electronic
thermal
overload
Percentage of electronic
overload attained
0 to 100%
07 LAD
frequency
Internal ramp generator
frequency
0 to max. frequency in Hz
