Motor Overload Protection
Hitachi L300P inverters provide solid state motor overload protection,
which depends on the proper setting of the following parameters:
• B012 “electronic overload protection”
• B212 “electronic overload protection, 2nd motor”
Set the rated current [Amperes] of the motor(s) with the above parame-
ters. The setting range is 0.2 * rated current to 1.2 * rated current.
Warning: When two or more motors are connected to the
inverter, they cannot be protected by the electronic overload pro-
tection. Install an external thermal relay on each motor.
400V Models
Motor output
Inverter Model
Ampere Rating for
Fuse or Breaker
kW HP
1.5 2 –015HFU2/E2 10
2.2 3 –022HFU2/E2 10
4.0 5 –037HFU2/E2 15
5.5 7 1/2 –055HFU2/E2 15
7.5 10 –075HFU2/E2 20
11 15 –110HFU2/E2 30
15 20 –150HFU2/E2 35
18.5 25 –185HFU2/E2 50
22 30 –220HFU2/E2 50
30 40 –300HFU2/E2 70
37 50 –370HFU2/E2 80
45 60 –450HFU2/E2 100
55 75 –550HFU2/E2 125
75 100 –750HFU2/E2 150
90 125 –900HFU2/E2 200
110 150 –1100HFU2/E2 225
132 175 –1320HFU2/E2 300
