Hitachi L300P Series Quick Reference Guide

35
Programming Error Codes
The L300P inverter operator keypad displays a special code (begins with
the character) to indicate a programming error. Programming errors
exist when one parameter conflicts with the meaningful range permitted
by related parameter(s). Note that particular real-time frequency (speed)
input levels can cause a conflict in some situations. After a conflict exists,
the error code will appear on the display, or you can view it later with
D090 in Monitor Mode. Also, the PGM LED on the display will flash
ON/OFF when programming. These indications are automatically cleared
when the parameter is corrected to the allowed range.
Prg Error Code
Function code of
parameter out of
bounds
Boundary defined by...
<, > Base parameter
001 201
A061 / A261 > A004 / A204
002 202
A062 / A262 >
004 204
A003 / A203 >
005 205
F001, A020 / A220 >
006 206
A021 to A035 >
012 212
A062 / A262 > A061 / A261
015 215
F001, A020 / A220 >
016 216
A021 to A035 >
021 221
A061 / A261 < A062 / A262
025 225
F001, A020 / A220 <
031 231
A061 / A261 < B082
032 232
A062 / A262 <
035 235
F001, A202 / A220 <
036
A021 to A035 <
037
A038 <
