Hitachi L300P Series Instruction Manual Supplement

L300P Supplement Explanation of functions
Function Mode
A041 Torque boost selection 00 (manual torque boost) / 01 (automatic torque boost) 00 00
A241
Torque boost selection,
2
nd
motor
00 (manual torque boost) / 01 (automatic torque boost) 00 00
A042 Manual torque boost 0.0-20.0(%) 1.0 1.0
A242
Manual torque boost, 2
nd
Motor
0.0-20.0(%) 1.0 1.0
A043 Manual torque boost point 0.0-50.0(%) 5.0 5.0
A243
Manual torque boost point,
2
nd
motor
0.0-50.0(%) 5.0 5.0
A044 1
st
control 00/(VC)/01(VP1.7power)/02(free V/f setting) 01 00
A244 2
nd
control 00/(VC)/01(VP1.7power)/02(free V/f setting) 01 00
V/f characteristic
A045 Output voltage gain 20. - 100. 100. 100.
A051 DC braking selection 00(invalid)/01(valid) 00 00
A052 DC braking frequency 0.00-60.00(Hz) 0.50 0.50
A053 DC braking wait time 0.0 - 5.0(s) 0.0 0.0
A054 DC braking power 0. - 70. (%) 0. 0.
A055 DC braking time 0.0 - 60.0(s) 0.0 0.0
A056
DC braking edge/level
Selection
00(edge action) / 01(level action) 01 01
A057
DC braking power (starting
time)
0. - 70. (%) 0. 0.
A058 DC braking time(starting time) 0.00-60.0(s) 0.0 0.0
Direct current braking
A059 DC carrier frequency 0.5-12(kHz) Derating 3.0 3.0
Code Function name Setting range
LBRM/HFBM
Initial Data
LFU/HFU
Initial data
