L300P Supplement Explanation of functions
Function Mode
Code Function name Setting range
LBRM/HFBM
Initial Data
LFU/HFU
Initial data
A001
Frequency
setting selection
00(VR)/01(terminal)/02(operator)/03(RS485)/
04(option1)/05(option2)
01 01
A002
Operation
setting selection
01(terminal)/02(operator)/03(RS485)/04(option1)/05(option2) 01 01
A003 Base frequency, 30. - maximum. frequency (Hz) 60. 60.
A203
Base frequency,
2nd motor
30. - 2
nd
braking maximum. frequency (Hz) 60. 60.
A004 Maximum frequency 30. - 400. (Hz) 60. 60.
Base setting
A204
Maximum frequency,
2nd motor
30. - 400. (Hz) 60. 60.
A005 AT terminal selection
00( Changing of O and OI with AT terminal)/
01(Changing of O and O2 with AT terminal)
00 00
A006 02 selection
00(single)/01(auxiliary speed of O, OI) [no reversible]/
02(auxiliary speed of O, OI [reversible]
00 00
A011 0 start 0.00-99.99/100.0-400.0 (Hz) 0.00 0.00
A012 0 end 0.00-99.99/100.0-400.0 (Hz) 60.00 0.00
A013 0 start rate 0.-100.0 (%) 0. 0.
A014 0 end rate 0.-100.0(%) 100. 100.
A015 0 start selection 00 (external starting frequency)/01(0Hz) 01 01
Analog input setting
A016 O, OI, O2 sampling 1.-30.(times) 8. 8.
A019 Multi-speed selection
00(binary : range is to 16 stage speed with 4 terminals)/
01(bit : range is to 6 stage speed with 5 terminals)
00 00
A020 Multi-speed 0 0.00, starting frequency-maximum. frequency(Hz)
NOTE (1)
15.00
0.00
A220 Multi-speed 0, 2
nd
motor 0.00, starting frequency-2
nd
braking maximum frequency(Hz)
NOTE (1)
15.00
0.00
A021 Multi-speed1 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A022 Multi-speed2 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A023 Multi-speed3 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A024 Multi-speed4 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A025 Multi-speed5 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A026 Multi-speed6 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A027 Multi-speed7 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A028 Multi-speed8 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A029 Multi-speed9 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A030 Multi-speed10 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A031 Multi-speed11 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A032 Multi-speed12 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A033 Multi-speed13 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A034 Multi-speed14 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A035 Multi-speed15 0.00, starting frequency-maximum frequency(Hz)
NOTE (1)
15.00
0.00
A038 Jogging frequency 0.00, starting frequency-9.99(Hz) 1.00 1.00
Multistage speed・jogging frequency setting
A039 Jogging selection
00(free-run on JG stop / invalid on running) /
01(stop decelerating on JG stop / invalid on running) /
02(DC braking on JG stop/invalid on running) /
03(free-run on JG stop/valid on running
[JG after stop decelerating]) /
04 (stop decelerating on JG stop/valid on running) /
05 (DC braking on JG stop/valid on operating)
00 00
5
