Ethernet management ports 0 and 1
Standard 10/100/1000 Ethernet ports, used to connect to the server for management
purposes.
Serial port
A standard serial (RS-232) port, used to connect to the server for management purposes.
See RS-232 serial management port (on page 60) for mor
e information.
USB ports
Standar
d USB 2.0 (Universal Serial Bus 2.0) connectors. These ports are used to connect
USB devices to the server during some operations.
Valid USB devices include:
■
Flash drives
■
External hard drives
■
USB keyboards
Valid operations include:
■
Management
■
Install
■
Upgrade
■
Update
■
Repair
Note: The USB ports should not be used without guidance fr
om
customer
support.
Management interfaces
The server panel featur
es two types of physical management ports: RS-232 Serial (DB-9)
and 10/100/1000 Ethernet (RJ45).
Ethernet management ports 0 and 1
