English
14
䡺 THE PUSH LEVER AND TRIGGER MUST MOVE SMOOTHLY.
(2) Adjust the air pressure to 70 psi (4.9 bar 5 kgf/cm
2
).
Connect the air hose.
Do not load any nails in the Nailer.
Set the switching device to the upward position (SINGLE ACTUATION MECHANISM).
(Set the switching device to the upward position completely as shown in the diagram.
Otherwise, it will not operate properly.)
䡺 THE NAILER MUST NOT LEAK AIR.
(3) Remove the finger from the trigger and press the push lever against the wood.
䡺 THE NAILER MUST NOT OPERATE.
Do not connect
air hose
Trigger
Push lever
Depress push lever
Do not pull trigger
Switching Device
Upward position
01Eng_NT50AE2M2_US 10/4/06, 15:4814
