OPERATION
NOTE:
The information contained in this Manual is designed to assist you in the safe
operation of the Nailer.
Some illustrations in this Manual may show details or attachments that differ from
those on your own Nailer.
NAME OF PARTS
NT50AE(S)
Firing Head (Outlet)
Magazine
Stopper
Air PlugBody
Top Cover
Trigger
Push Lever
Blade Guide
Guide Plate (A)
Driver Blade
Piston O-ring
Exhaust Cover
Magazine (A)Feed SpringNail Feeder Magazine (B)
Lock Lever
Adjuster
