Hitachi NT 65M - EXHAUST DIRECTION AND NOSE CAP

English
23
CHANGING THE EXHAUST DIRECTION
WARNING
● When changing the exhaust direction, be sure to remove your
finger from the trigger and disconnect the air hose from the nailer.
The direction of the exhaust vent can be changed by turning the top cover.
USING THE NOSE CAP
WARNING
● When attaching or detaching the nose cap, be sure to remove
your finger from the trigger and disconnect the air hose from the
nailer.
If you like to protect the surface of workpiece against scratches or markings made by the
push lever, attach the accessory nose cap to the push lever.
1 DISCONNECT AIR HOSE FROM NAILER.
2 Put the nose cap to the toe of the push lever.
NOTE:
● The nose cap may reduce nailing depth due to its thickness. Re-adjustment of nailing
depth is required.
Exhaust
Vent
Top Cover
Disconnect
air hose
Nose Cap
Push
Lever
2
1
