Part NV 45AB2 NV 45AB
Nail Guide Shaft
[74]
Nail Guide [78]
Magazine Ass'y
[109]
A groove for mounting the shaft ring is
provided.
A protrusion for holding the magazine cover
is provided.
Protrusion
Top loading type
The newly designed nail guide is required to
close the magazine cover.
It can be mounted to the newly designed
body only.
Following parts are common to the Model
NV 45AB.
Plate Nut [104]
Guide Base [105]
Shingle Guide [107]
Hex. Socket Hd. Bolt M5x10 [108]
Groove
Bottom loading type
