DISASSEMBLY INSTRUCTIONS
1.
2.
3.
4.
Check if the wire placement is correct.
Check if the cushion positions are correct.
Check if the tape positions are correct.
Install the Cabinet Back and Cover Back. (Refer to 1-1: CABINET BACK/COVER BACK)
1-9: CABINET BACK/COVER BACK
Before install the Cabinet Back, check if the Bond (PART NO.: Y118011000), Flame Retadant Tape and
UL Tape as shown in the photo.
1-8: CHASSIS BLOCK9
1.
Bond
Bond
Bond
Bond
Tape
Tape
Tape
PDP Module
Bond
Bond
Bond
Bond
STANDARD LINE
STANDARD LINE
To Next Page
