8.1 Replenishing the ink
(1) Overview
●Replenish the ink in the ink reservoir within 60 minutes after an Ink Low warning is generated. If the ink is
not replenished, the printer will stop.
●The ink can be replenished without regard to whether the IJ printer power is ON or OFF or the printer’s
operating state.
●When the ink is replenished, the warning is automatically reset.
(2) Operation
Open the maintenance cover, pull the reservoir base forward, and remove the
cap of the ink reservoir.
1
Remove the cap from the ink bottle and replenish the ink by pouring it into the
ink reservoir.
●Be sure that the ink reservoir ink level does not exceed the MAX line.
2
Close the ink reservoir cap.
●Tighten the cap securely. The solvent component may evaporate.
3
Return the reservoir base to its original position.
4
Close the maintenance cover. 5
Cap
Close
Open
Ink reservoir
Reservoir base
Maintenance cover
Cap
MAX line
Ink reservoir
Ink level
MAX line
Ink reservoir
Ink bottle
