Hitachi UX2-D160W - User Manual

Hitachi UX2-D160W
300 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
HITACHI
Printer
Model UX2
Instruction Manual
● Before using the printer, thoroughly read this instruction manual for
optimum printer use.
● After reading the manual, properly keep it for future reference.

Table of Contents

Other manuals for Hitachi UX2-D160W

Preview: Basic Operation Manual
Basic Operation Manual70 pages

Questions and Answers

  • J
    Jennifer MillsAug 8, 2025
    How to fix Hitachi Printer if the power does not turn ON?
    • A
      Anthony PattersonAug 8, 2025
      If the power does not turn ON when you press the ON switch on your Hitachi Printer, first, turn ON the main power switch. If that doesn't work, turn OFF the main power switch, ensure the power outlet is active, and then connect the power plug securely. As an alternative, make sure the status indicator lamp is OFF before pressing the ON switch. Turn the main power switch OFF and then ON again after ten seconds, then try pressing the ON switch for about two seconds.
  • P
    Paul TurnerAug 13, 2025
    What to do if Hitachi Printer does not become ready for printing when STARTUP is pressed?
    • J
      John ArmstrongAug 13, 2025
      If your Hitachi Printer unit doesn't become ready for printing even after pressing STARTUP, stop the ink ejection by pressing Stop. Then, consult the Technical Manual section "5.5. Stream alignment" to correct the problem. Alternatively, see section "1.2.3. Print Head Cleaning" to clean the print head.
  • C
    Cody ThompsonAug 18, 2025
    What to do if remote operation does not work on Hitachi Printer?
    • B
      Brandon DavisAug 18, 2025
      If the remote operation on your Hitachi Printer isn't working even when the signal is input, close the window and display the [HOME] screen. Then, input the signal again.
  • A
    Andrew JosephAug 23, 2025
    Why does after-image of characters remain on the screen of Hitachi Printer?
    • J
      Joel PhillipsAug 23, 2025
      If you're seeing an after-image of characters remaining on the screen of your Hitachi Printer, it's due to the characteristics of the LCD panel. When the same pattern is displayed for an extended period, this after-image may appear, but it should disappear over time.
  • A
    Austin VasquezAug 28, 2025
    How to correct the printed calendar time on Hitachi Printer?
    • A
      ashleelongAug 28, 2025
      If the printed calendar time is incorrect on your Hitachi Printer, set the current date and time as the calendar time. Refer to section "9.2. Setting Date and Time."
  • M
    Mary McconnellSep 2, 2025
    What to do if RFID cannot be read by Hitachi Printer?
    • A
      Amy EdwardsSep 2, 2025
      If the RFID cannot be read by your Hitachi Printer, the tag may be broken. Manually input the ID according to "Chapter 8. Ink and Makeup Replenishment."

Summary

Important Notes

Precautions before using the product

Thoroughly read manual and related documents before use; follow all instructions for proper use.

Safety Precautions

Installation Environment

Chapter 1. Overview

Usage Precautions

Covers essential precautions for proper product use, including ink/makeup handling.

Chapter 3. Component Names and Functions

Print Head

Describes the internal structure and components of the print head assembly.

Chapter 4. Basic Operation

Basic Operation Flow

Outlines the fundamental operating procedures and the system's operational scheme.

Start Operation

Provides detailed steps for safely starting the printer unit and its initial procedures.

Shutdown Operation

Explains various methods for safely stopping and shutting down the printer unit.

Chapter 5. Creation and Setting of Print Messages

Editing Messages to be Printed (Message Edit Screen)

Details how to edit the current message using the message edit screen and its features.

Calling and Printing Saved Messages

Saving Created Messages

Setting Print Format (Fixed Layout)

Guides through setting the print format, including selecting print items and defining layout parameters.

Setting Print Specifications

Details how to configure print specifications like character height, width, orientation, and print start delay.

Chapter 6. Character Print

Printing Characters

Chapter 7. Auxiliary Functions

Managing Messages

Creating User Pattern

Back Up Data to USB Memory

Explains how to back up messages and user patterns to USB memory for data safety.

Chapter 8. Ink and Makeup Replenishment

Replenishing Ink

Provides detailed steps and precautions for refilling ink into the printer's ink reservoir.

Replenishing Makeup

Details the procedure and precautions for refilling makeup into the printer's makeup reservoir.

Chapter 10. Maintenance

Checking Operational Status

Chapter 11. Safe Clean Station (Optional parts)

Setting Head Cleaning Mode

Head Cleaning Using Head Cleaning Station

Details the step-by-step procedure for cleaning the print head using the cleaning station.

Starting Operation Using Cleaning station

Guides on initiating the printer's operation sequence after using the cleaning station.

Chapter 12. When Fault or Warning Occurs

Display When Fault or Warning Occurs

On-screen Message Descriptions

Provides a comprehensive list of fault and warning messages with their descriptions and solutions.

Checking Fault and Warning Occurrence Status

Action to be Taken in Event of Printing Failure

Offers a troubleshooting guide for common printing failures, listing causes and solutions.

Chapter 13. Troubleshooting Guide

Chapter 14. Emergency Procedures

Hitachi UX2-D160W Specifications

General IconGeneral
BrandHitachi
ModelUX2-D160W
CategoryPrinter
LanguageEnglish
