Hitachi S1 Series User Manual

S1 series standard inverter
-228-
13.2 STO channel delay description
The following table describes the trigger and indication delay of the STO channels.
STO mode
STO trigger and indication delay
1, 2
STO fault: STL1
Trigger delay < 10 ms
Indication delay < 280 ms
STO fault: STL2
Trigger delay < 10 ms
Indication delay < 280 ms
STO fault: STL3
Trigger delay < 10 ms
Indication delay < 280 ms
STO fault: STO
Trigger delay < 10 ms
Indication delay < 100 ms
1. STO function trigger delay: Time interval between trigger the STO function and switching off the
drive output
2. STO instruction delay: Time interval between trigger the STO function and STO output state
indication
13.3 STO function installation checklist
Before installing the STO, check the items described in the following table to ensure that the STO
function can be properly used.
Item
□
Ensure that the drive can be run or stopped randomly during commissioning.
□
Stop the drive (if it is running), disconnect the input power supply, and isolate the drive
from the power cable through the switch.
□
Check the STO circuit connection according to the circuit diagram.
□
Check whether the shielding layer of the STO input cable is connected to the +24 V
reference ground COM.
□
Connect the power supply.
□
Test the STO function as follows after the motor stops running:
• If the drive is running, send a stop command to it and wait until the shaft of the
motor stops rotating.
• Activate the STO circuit and send a start command to the drive. Ensure that the
motor does not start.
• Deactivate the STO circuit.
□
Restart the drive, and check whether the motor is running properly.
□
Test the STO function as follows when the motor is running:
• Start the drive. Ensure that the motor is running properly.
• Activate the STO circuit.
• The drive reports an STO fault (for details, see section 7.5 "Inverter faults and
solutions"). Ensure that the motor coasts to stop rotating.
• Deactivate the STO circuit.
□
Restart the drive, and check whether the motor is running properly.

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
