Hitachi S1 Series User Manual

S1 series standard inverter
-61-
Function
code
Name
Detailed parameter description
Default
value
P01.22
Waiting time of restart after
power down
0.0–3600.0s (valid when P01.21 is 1)
1.0s
P01.23
Start delay
0.0–60.0s
0.0s
P01.24
Stop speed delay
0.0–100.0s
0.0s
P01.25
Open-loop 0Hz output
selection
0: No voltage output
1: With voltage output
2: Output as per DC brake current of stop
0
P01.26
Deceleration time of
emergency-stop
0.0–60.0s
2.0s
P01.27
Time of starting section of
deceleration S curve
0.0–50.0s
0.1s
P01.28
Time of ending section of
deceleration S curve
0.0–50.0s
0.1s
P01.29
Short-circuit brake current
0.0–150.0% (rated inverter current)
0.0%
P01.30
Hold time of short-circuit
brake at startup
0.00–50.00s
0.00s
P01.31
Hold time of short-circuit
brake at stop
0.00–50.00s
0.00s
P05.01–
P05.06
Digital input function
selection
1: Forward running
2: Reverse running
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
21: Acceleration/deceleration time
selection 1
22: Acceleration/deceleration time
selection 2
30: Acceleration/deceleration disabled
/
P08.06
Running frequency of
jogging
0.00Hz–P00.03 (Max. output frequency)
5.00Hz
P08.07
Acceleration time at jogging
0.0–3600.0s
Depend
on model
P08.08
Deceleration time at jogging
0.0–3600.0s
Depend
on model
P08.00
Acceleration time 2
0.0–3600.0s
Depend
on model

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
