Hitachi S1 Series User Manual

S1 series standard inverter
-71-
Function
code
Name
Detailed parameter description
Default
value
11: Analog AI2 input value
12: Analog AI3 input value
13: Input value of high-speed pulse
HDI/HDIA
14: Set value 1 of Modbus
communication
15: Set value 2 of Modbus
communication
16 - 21: Seserved
22: Torque current (bipolar, 100%
corresponds to 10V)
23: Ramps reference frequency
(bipolar)
P06.17
Lower limit of AO1 output
-100.0%–P06.19
0.0%
P06.18
Corresponding AO1 output of
lower limit
0.00V–10.00V
0.00V
P06.19
Upper limit of AO1 output
P06.17–100.0%
100.0%
P06.20
Corresponding AO1 output of
upper limit
0.00V–10.00V
10.00V
P06.21
AO1 output filter time
0.000s–10.000s
0.000s
P06.22–
P06.26
Reserved variable
0–65535
0
P06.27
Lower limit of HDO output
-100.0%–P06.29
0.0%
P06.28
Corresponding HDO output of
lower limit
0.00–50.00kHz
0.0kHz
P06.29
Upper limit of HDO output
P06.27–100.0%
100.0%
P06.30
Corresponding HDO output of
upper limit
0.00–50.00kHz
50.00kHz
P06.31
HDO output filter time
0.000s–10.000s
0.000s
5.5.10 Digital input
S1 series inverter carries four programmable digital input terminals and two HDI input terminals. The
function of all the digital input terminals can be programmed by function codes. HDI input terminal can
be set to act as high-speed pulse input terminal or common digital input terminal; if it is set to act as
high-speed pulse input terminal, users can also set HDIA or HDIB high-speed pulse input to serve as
the frequency reference and encoder signal input.

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
