S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
24
*4 All GP models except GP-3200 Series and AGP-3302B
*5 All GP4000 models except GP-4100 Series, GP-4*01TM, GP-Rear Module, GP-4201T and GP-4*03T
*6 Except SP-5B00
*7 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block
Conversion Adapter, refer to Cable Diagram 1A.
*8 Available to use only the COM ports which can communicate in RS422/485(4 wire).
)" IPC COM Port" (page 4)
• Termination resistance (100Ω) between RD-H and RD-L is incorporated in the LPU module
and LQE565 of the External Device.
To Next Page
