Hitachi S10 Series User Manual

S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
44
7 Device Code and Address Code
Use device code and address code when you select "Device Type & Address" for the address type in data
displays.
7.1 S10V Series
Device
Device
Name
Device Code
(HEX)
Address Code
External Input
X
0080 Value of word address divided by 0x10
XW
External Output
Y
0081 Value of word address divided by 0x10
YW
Internal Register
R
0082 Value of word address divided by 0x10
RW
Global Link Register
G
0083 Value of word address divided by 0x10
GW
Event Register
E
0084 Value of word address divided by 0x10
EW
Event Register
EW
0091 Value of word address divided by 0x10
EW
Keep Relay
K
0085 Value of word address divided by 0x10
KW
System Register
S
0086 Value of word address divided by 0x10
SW
On-delay Timer
T
0087 Value of word address divided by 0x10
TW
One-shot Timer
U
0088 Value of word address divided by 0x10
UW
Up-Down Counter
C
0089 Value of word address divided by 0x10
CW
Transfer Register
J
008A Value of word address divided by 0x10
JW
Receive Register
Q
008B Value of word address divided by 0x10
QW
Extended Internal Register
M
008C Value of word address divided by 0x10
MW
Extended Internal Register
A
008D Value of word address divided by 0x10
AW
