Hitachi S10 Series User Manual

S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
47
7.2 HIDIC-S10α (2α/2αE/2αH)
Device
Device
Name
Device Code
(HEX)
Address Code
External Input
X
0080 Value of word address divided by 0x10
XW
External Output
Y
0081 Value of word address divided by 0x10
YW
Intermediate Register
R
0082 Value of word address divided by 0x10
RW
Global Link Register
G
0083 Value of word address divided by 0x10
GW
Event Register
E
0084 Value of word address divided by 0x10
EW
Keep Relay
K
0085 Value of word address divided by 0x10
KW
System Register
S
0086 Value of word address divided by 0x10
SW
Timer
T
0087 Value of word address divided by 0x10
TW
One Shot
U
0088 Value of word address divided by 0x10
UW
Counter
C
0089 Value of word address divided by 0x10
CW
Transfer Register
J
008A Value of word address divided by 0x10
JW
Receive Register
Q
008B Value of word address divided by 0x10
QW
Extended Internal Register
M
008C Value of word address divided by 0x10
MW
On-Delay Timer (Elapsed Value) TC 0060 Word Address
On-Delay Timer (Setup Value) TS 0061 Word Address
One Shot Timer (Elapsed Value) UC 0062 Word Address
One Shot Timer (Setup Value) US 0063 Word Address
Up/Down Counter (Elapsed Value) CC 0064 Word Address
Up/Down Counter (Setup Value) CS 0065 Word Address
Function Work Register FW 0001 Word Address
Function Data Register DW 0000 Word Address
Extended Register MS 0006 Word Address
