Hitachi S10 Series User Manual

S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
38
6.2 HIDIC-S10α (2α/2αE/2αH)
: This address can be specified as system data area.
Device Bit Address Word Address 32 bits Remarks
External Input X000 - XFFF XW000 - XWFF0
*1
External Output Y000 - YFFF YW000 - YWFF0
*1
Intermediate Register R000 - RFFF RW000 - RWFF0
*1
Global Link Register G000 - GFFF GW000 - GWFF0
*1
Event Register E000 - E3FF EW000 - EW3F0
*1
Keep Relay K000 - KFFF KW000 - KWFF0
*1
System Register S000 - SBFF SW000 - SWBF0
*1 *2
Timer T000 - T1FF TW000 - TW1F0
*1
One Shot U000 - U0FF UW000 - UW0F0
*1
Counter C000 - C0FF CW000 - CW0F0
*1
Transfer Register J000 - JFFF JW000 - JWFF0
*1
Receive Register Q000 - QFFF QW000 - QWFF0
*1
Extended Internal Register M000 - MFFF MW000 - MWFF0
*1
On-Delay Timer (Elapsed Value) - TC000 - TC1FF
On-Delay Timer (Setup Value) - TS000 - TS1FF
One Shot Timer (Elapsed Value) - UC000 - UC0FF
One Shot Timer (Setup Value) - US000 - US0FF
Up/Down Counter (Elapsed
Value)
- CC000 - CC0FF
Up/Down Counter (Setup Value) - CS000 - CS0FF
