Hitachi S10 Series User Manual

S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
35
6 Supported Device
Range of supported device address is shown in the table below. Note that the actually supported range varies
depending on the External Device to be used. Please check the actual range in the manual of your External
Device.
6.1 S10V Series
: This address can be specified as system data area.
Device Bit Address Word Address 32 bits Remarks
External Input X000 - XFFF XW000 - XWFF0
*1
External Output Y000 - YFFF YW000 - YWFF0
*1
Internal Register R000 - RFFF RW000 - RWFF0
*1
Global Link Register G000 - GFFF GW000 - GWFF0
*1
Event Register E000 - E3FF EW000 - EW3F0
*1
Event Register EW400 - EWFFF EW400 - EWFF0
*1 *2
Keep Relay K000 - KFFF KW000 - KWFF0
*1
System Register S000 - SBFF SW000 - SWBF0
*1 *3
On-delay Timer T000 - T7FF TW000 - TW7F0
*1 *4
One-shot Timer U000 - U0FF UW000 - UW0F0
*1
Up-Down Counter C000 - C0FF CW000 - CW0F0
*1
Transfer Register J000 - JFFF JW000 - JWFF0
*1
Receive Register Q000 - QFFF QW000 - QWFF0
*1
Extended Internal Register M000 - MFFF MW000 - MWFF0
*1
Extended Internal Register A000 - AFFF AW000 - AWFF0
*1
