Hitachi S10 Series User Manual

S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
34
3G)
*1 The resistance in the Display is used as the termination resistance. Set the value of the DIP Switch on the
rear of the Display as shown in the table below.
• When making your own connections, we recommend using KPEV-SB-3P 0.5mm
2
cable by
Hitachi Cable, Ltd..
DIP Switch No. Set Value
1OFF
2OFF
3ON
4ON
RDA
RDB
SDA
SDB
SG
ERA
CSA
ERB
CSB
Signal name
Display
Terminal block
Termination
resistance *1
Your own cable
UTX-H
UTX-L
URX-H
URX-L
External Device
Shield
Signal name
Series resistance
100Ω (1/2W)
Display
