Hitachi S10 Series - Page 33

S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
33
3E)
3F)
• When making your own connections, we recommend using KPEV-SB-3P 0.5mm
2
cable by
Hitachi Cable, Ltd..
UTX-H
UTX-L
URX-H
URX-L
External Device
Shield
Signal name
TRM
RDA
RDB
SDA
SDB
SG
FG
Signal name
Display
Terminal block
Your own cable
Series resistance
100Ω (1/2W)
PFXZCBADTM1
Display
Rx+
Rx-
Tx+
Tx-
GND
NC
NC
NC
NC
FG
3
4
2
1
5
7
8
9
6
Shell
Signal name
Pin
Display
D-Sub 9pin (socket)
Termination
resistance
100Ω (1/2W)
Your own cable
UTX-H
UTX-L
URX-H
URX-L
External Device
Shield
Signal name
Series resistance
100Ω (1/2W)
Display
