Hitachi S10 Series User Manual

S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
45
Timer (Elapsed Value) TC 0060 Word Address
Timer (Setup Value) TS 0061 Word Address
One-shot Timer (Elapsed Value) UC 0062 Word Address
One-shot Timer (Setup Value) US 0063 Word Address
Counter (Elapsed Value) CC 0064 Word Address
Counter (Setup Value) CS 0065 Word Address
Work Register FW 0001 Word Address
Data Register DW 0000 Word Address
Work Register
LB
008E Value of word address divided by 0x10
LBW
Work Register for Ladder Converter
LR
008F Value of word address divided by 0x10
LRW
Work Register for Ladder Converter
(Edge)
LV
0090 Value of word address divided by 0x10
LVW
Work Register for Word LWW 0002 Word Address
Work Register for Long Word LLL 0003 Word Address
Work Register for Floating Point LF 0066 Word Address
Work Register for Word
(Save during power OFF)
LXW 0004 Word Address
Work Register for Long Word
(Save during power OFF)
LML 0005 Word Address
Work Register for Floating Point
(Save during power OFF)
LG 0067 Word Address
Direct Memory Address
(DM00000000 - DM0FFFFFFE)
DM
0007
Value of word address divided by 2
Direct Memory Address
(DM10000000 - DM1FFFFFFE)
0008
Direct Memory Address
(DM20000000 - DM2FFFFFFE)
0009
Direct Memory Address
(DM30000000 - DM3FFFFFFE)
000A
Direct Memory Address
(DM40000000 - DM4FFFFFFE)
000B
Direct Memory Address
(DM50000000 - DM5FFFFFFE)
000C
Direct Memory Address
(DM60000000 - DM6FFFFFFE)
000D
Direct Memory Address
(DM70000000 - DM7FFFFFFE)
000E
Device
Device
Name
Device Code
(HEX)
Address Code
