Hitachi S10 Series - Page 52

S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
52
Data Register DW 0000 Word Address
Extended Register MS 0006 Word Address
Direct Memory Address
(DM00000000 - DM0FFFFFFE)
DM
0007
Value of word address divided by 2
Direct Memory Address
(DM10000000 - DM1FFFFFFE)
0008
Direct Memory Address
(DM20000000 - DM2FFFFFFE)
0009
Direct Memory Address
(DM30000000 - DM3FFFFFFE)
000A
Direct Memory Address
(DM40000000 - DM4FFFFFFE)
000B
Direct Memory Address
(DM50000000 - DM5FFFFFFE)
000C
Direct Memory Address
(DM60000000 - DM6FFFFFFE)
000D
Direct Memory Address
(DM70000000 - DM7FFFFFFE)
000E
Direct Memory Address
(DM80000000 - DM8FFFFFFE)
000F
Direct Memory Address
(DM90000000 - DM9FFFFFFE)
0010
Direct Memory Address
(DMA0000000 - DMAFFFFFFE)
0011
Direct Memory Address
(DMB0000000 - DMBFFFFFFE)
0012
Direct Memory Address
(DMC0000000 - DMCFFFFFFE)
0013
Direct Memory Address
(DMD0000000 - DMDFFFFFFE)
0014
Direct Memory Address
(DME0000000 - DMEFFFFFFE)
0015
Direct Memory Address
(DMF0000000 - DMFFFFFFFE)
0016
Device
Device
Name
Device Code
(HEX)
Address Code
