Hitachi SJ100 Series

Parameter Settings for DOP/DRW/DOP Plus
Appendix B
B–10
Function Mode Setup
Mon. Analog voltage input
adjustment
ADJ-O 097 ADJ-O 097
Analog current input
adjustment
ADJ-OI 079 ADJ-OI 079
Analog adjustment ADJ 080 ADJ 080
Panel display selection PANEL d01 PANEL d01
Terminal monitor TERM LLL LLLLLL TERM LLL LLLLLL
Accumulation of Run
Mode time since mfg.
RUN 000003H RUN 000003H
Alarm display ERR1 Under.V ERR1 Under.V
ERR1 10.0Hz ERR1 10.0Hz
ERR1 0.2A ERR1 0.2A
ERR1 189.8Vdc ERR1 189.8Vdc
ERR1 RUN 000003H ERR1 RUN 000003H
Total alarm count ERROR COUNT 002 ERROR COUNT 002
Trip history, previous
alarm (example)
ERR2 Under.V ERR2 Under.V
ERR2 10.0Hz ERR2 10.0Hz
ERR2 0.2A ERR2 0.2A
ERR2 189.8Vdc ERR2 189.8Vdc
ERR2 RUN 000003H ERR2 RUN 000003H
Trip history, 2nd
previous alarm
ERR3 # ERR3 #
Monitor Mode Setup Displayed Default Setting
User Setting
Func.
Code
Name -FE (Europe) -FU (USA)
Function Mode Setup Displayed Default Setting
User Setting
Func.
Code
Name -FE (Europe) -FU (USA)
F-00
Base frequency setting F-BASE 050Hz F-BASE 060Hz
F-01
Maximum frequency
setting
F-MAX 050Hz F-MAX 060Hz
F-02
Start frequency adjust-
ment
Fmin 0.5Hz Fmin 0.5Hz
F-03
Motor input voltage AVR AC 230V AVR AC 230V
AVR function for decel-
eration
AVR MODE DOFF AVR MODE DOFF
