Hitachi SJ100 Series

SJ100 Inverter
Appendix B
B–11
F-04
Control method setting CONTROL SLV CONTROL SLV
F-05
Auto-tuning setting AUX AUTO NOR AUX AUTO NOR
Motor date selection AUX DATA NOR AUX DATA NOR
Motor date selection,
2nd motor
2AUXDATA NOR 2AUXDATA NOR
Motor capacity setting AUX K 0.4 kW AUX K 0.4 kW
Motor capacity setting,
2nd motor
2AUXK 0.4 kW 2AUXK 0.4 kW
Motor pole count setting AUX P 4p AUX P 4p
Motor pole count
setting, 2nd motor
2AUXP 4p 2AUXP 4p
Motor constant R1
setting
AUX R1 06.333ô AUX R1 05.700ô
Motor constant R1
setting, 2nd motor
2AUXR1 06.333ô 2AUXR1 05.700ô
Motor constant R2
setting
AUX R2 03.200ô AUX R2 02.773ô
Motor constant R2
setting, 2nd motor
2AUXR2 03.200ô 2AUXR2 02.773ô
Motor constant L setting AUX L 027.50mH AUX L 045.70mH
Motor constant L
setting, 2nd motor
2AUXL 027.50mH 2AUXL 045.70mH
Motor constant IO
setting
AUX I0 001.48A AUX I0 001.50A
Motor constant IO
setting, 2nd motor
2AUXI0 001.48A 2AUXI0 001.50A
Motor constant J setting AUX J 0020.0 AUX J 0020.0
Motor constant J setting,
2nd motor
2AUXJ 0020.0 2AUXJ 0020.0
Motor constant Kp
setting
AUX KP 20 AUX KP 20
Motor constant Kp
setting, 2nd motor
2AUXKP 20 2AUXKP 20
Motor stabilization
constant setting
AUX KCD 100 AUX KCD 100
Motor stabilization
constant, 2nd motor
2AUXKCD 100 2AUXKCD 100
Function Mode Setup Displayed Default Setting
User Setting
Func.
Code
Name -FE (Europe) -FU (USA)
