Chapter 1 Overview
1 - 4
1.3 Exterior Views and Names of Parts
The figure below shows an exterior view of the inverter (model SJ700B-185LFF/LFUF/HFF/HFUF to
300LFF/LFUF/HFF/HFUF).
Exterior view of shipped inverter
For the wiring of the main circuit and control circuit terminals, open the terminal block cover.
For mounting optional circuit boards, open the front cover.
Exterior view of inverter with front and terminal block covers removed
Front cover
POWER lamp
ALARM lamp
Terminal block cover
Spacer cover
Digital operator
Specification label
Position to mount optional board 1
Main circuit terminals
Backing plate
Control circuit terminals
Position to mount optional board 2
