Hitachi SJ700B SERIES - Extended Function Mode

Chapter 4 List of Data Settings
4 - 4
4.4 Extended Function Mode
Default
Code Function name Monitored data or setting
_F/_FF _FUF
Setting
during
operation
(allowed or
not)
Change
during
operation
(allowed or
not)
A001
Frequency source setting 00 (keypad potentiometer) (*1), 01 (control circuit terminal block), 02 (digital
operator), 03 (RS485), 04 (option 1), 05 (option 2), 06 (pulse-string input),
07 (easy sequence), 10 (operation function result)
01
¯ ¯
A002
Run command source setting 01 (control circuit terminal block), 02 (digital operator), 03 (RS485), 04
(option 1), 05 (option 2)
01
¯ ¯
A003 Base frequency setting 30. to "maximum frequency " (Hz) 50. 60.
¯ ¯
A203 Base frequency setting, 2nd motor 30. to "maximum frequency, 2nd motor" (Hz) 50. 60.
¯ ¯
A303 Base frequency setting, 3rd motor 30. to "maximum frequency, 3rd motor" (Hz) 50. 60.
¯ ¯
A004 Maximum frequency setting 30. to 400. (Hz) 50. 60.
¯ ¯
A204 Maximum frequency setting, 2nd motor 30. to 400. (Hz) 50. 60.
¯ ¯
Basic settings
A304 Maximum frequency setting, 3rd motor 30. to 400. (Hz) 50. 60.
¯ ¯
A005
[AT] selection 00 (switching between O and OI terminals), 01 (switching between O and
O2 terminals), 02 (switching between O terminal and keypad potentiometer)
(*1), 03 (switching between OI terminal and keypad potentiometer) (*1), 04
(switching between O2 and keypad potentiometer) (*1)
00
¯ ¯
A006
[O2] selection 00 (single), 01 (auxiliary frequency input via O and OI terminals)
(nonreversible), 02 (auxiliary frequency input via O and OI terminals)
(reversible), 03 (disabling O2 terminal)
03
¯ ¯
A011 [O]-[L] input active range start frequency 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
¯ {
A012 [O]-[L] input active range end frequency 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
¯ {
A013 [O]-[L] input active range start voltage 0. to "[O]-[L] input active range end voltage" (%) 0.
¯ {
A014 [O]-[L] input active range end voltage "[O]-[L] input active range start voltage" to 100. (%) 100.
¯ {
A015
[O]-[L] input active range start frequency
selection
00 (external start frequency), 01 (0 Hz)
01
¯ {
A016 External frequency filter time const. 1. to 30. or 31. (500 ms filter ±0.1 Hz with hysteresis) 31.
¯ {
Analog input and others
A017 Easy sequence function selection 00 (disabling), 01 (enabling) 00
¯ ¯
A019
Multispeed operation selection 00 (binary: 16 speeds selectable with 4 terminals), 01 (bit: 8 speeds
selectable with 7 terminals)
00
¯ ¯
A020 Multispeed frequency setting 0.0 or “start frequency” to “maximum frequency” (Hz) 0.00
{ {
A220 Multispeed frequency setting, 2nd motor 0.0 or “start frequency” to “maximum frequency, 2nd motor” (Hz) 0.00
{ {
A320 Multispeed frequency setting, 3rd motor 0.0 or “start frequency” to “maximum frequency, 3rd motor” (Hz) 0.00
{ {
A021 Multispeed 1 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A022 Multispeed 2 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A023 Multispeed 3 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A024 Multispeed 4 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A025 Multispeed 5 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A026 Multispeed 6 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A027 Multispeed 7 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A028 Multispeed 8 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A029 Multispeed 9 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A030 Multispeed 10 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A031 Multispeed 11 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A032 Multispeed 12 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A033 Multispeed 13 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A034 Multispeed 14 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A035 Multispeed 15 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
{ {
A038 Jog frequency setting "Start frequency" to 9.99 (Hz) 1.00
{ {
Multispeed operation and jogging
A039 Jog stop mode
00 (free-running after jogging stops [disabled during operation]), 01
(deceleration and stop after jogging stops [disabled during operation]), 02
(DC braking after jogging stops [disabled during operation]), 03
(free-running after jogging stops [enabled during operation]), 04
(deceleration and stop after jogging stops [enabled during operation]), 05
(DC braking after jogging stops [enabled during operation])
00
¯ {
*1 This setting is valid only when the OPE-SR is connected.
