Hitachi SJ700B SERIES - Precautions for Data Setting; Monitoring Mode

Chapter 4 List of Data Settings
4 - 2
IMPORTANT! Please be sure to set the motor nameplate data into appropriate parameters to ensure
proper operation and protection of the motor.
*B012 is the motor overload protection value
*A082 is the motor voltage selection
*H003 is the motor kW capacity
*H004 is the number of motor poles
Please refer to the appropriate pages in this guide and the Instruction Manual for further details.
4.1 Precautions for Data Setting
The default display mode limits the screens (parameters) that can be displayed on the monitor. To enable
the display of all parameters, specify "00" (full display) for the function code display restriction (b037).
To enable the parameters to be changed while the inverter is operating, specify "10" for the software lock
mode selection (b031).
4.2 Monitoring Mode
With the default settings, the monitor always displays the data output according to the output frequency
monitoring (d001) after power-on. To change the initial display content, change the setting of the
initial-screen selection (b038) as required.
Code Function name Monitored data or setting Default
Setting
during
operation
(allowed or
not)
Change
during
operation
(allowed or
not)
d001 Output frequency monitoring 0.00 to 99.99, 100.0 to 400.0 (Hz)
−
{
−
d002 Output current monitoring 0.0 to 999.9, 1000 to 9999 (A)
− − −
d003 Rotation direction minitoring F (forward rotation), o (stopped), r (reverse rotation)
− − −
d004 Process variable (PV), PID feedback
monitoring
0.00 to 99.99, 100.0 to 999.9, 1000. to 9999.
1000 to 9999 (10000 to 99990), ⎡100 to ⎡999 (100000 to 999000)
− − −
d005 Intelligent input terminal status (Example)
Terminals FW, 7, 2, and 1: ON
Terminals 8, 6, 5, 4, and 3: OFF
− − −
d006 Intelligent output terminal status (Example)
Terminals 12 and 11: ON
Terminals AL, 15, 14, and 13: OFF
− − −
d007 Scaled output frequency monitoring 0.00 to 99.99, 100.0 to 999.9, 1000. to 9999., 1000 to 3996 (10000 to 39960)
−
{
−
d008 Actual-frequency monitoring -400. to -100., -99.9 to 0.00 to 99.99, 100.0 to 400.0 (Hz)
− − −
d009 Torque command monitoring -200. to +200. (%)
− − −
d010 Torque bias monitoring -200. to +200. (%)
− − −
d012 Torque monitoring -200. to +200. (%)
− − −
d013 Output voltage monitoring 0.0 to 600.0 (V)
− − −
d014 Power monitoring 0.0 to 999.9 (kW)
− − −
d015 Cumulative power monitoring 0.0 to 999.9, 1000. to 9999.
1000 to 9999 (10000 to 99990), ⎡100 to ⎡999 (100000 to 999000)
− − −
d016 Cumulative operation RUN time monitoring
0. to 9999., 1000 to 9999 (10000 to 99990), ⎡100 to ⎡999 (100000 to 999000) (hr) − − −
d017 Cumulative power-on time monitoring
0. to 9999., 1000 to 9999 (10000 to 99990), ⎡100 to ⎡999 (100000 to 999000) (hr) − − −
d018 Heat sink temperature monitoring
-020. to 200.0 (°C) − − −
d019 Motor temperature monitoring
-020. to 200.0 (°C) − − −
