Hitachi SJ700B SERIES Quick Reference Guide

Safety Instructions
v
11.Distribution fuse / circuit breaker size marking is included in the manual to indicate that the unit shall be
connected with a Listed inverse time circuit breaker, rated 600 V with the current ratings as shown in the
table below:
Model No. Fuse Size (Maximum A) Circuit Breaker (Maximum A)
Type Rating Type Rating
SJ700B-110L J 60 A Inverse time 60 A
SJ700B -150L J 100 A Inverse time 100 A
SJ700B 185L J 100 A Inverse time 100 A
SJ700B -220L J 100 A Inverse time 100 A
SJ700B -300L J 125 A Inverse time 125 A
SJ700B -370L J 175 A Inverse time 175 A
SJ700B -450L J 225 A Inverse time 225 A
SJ700B -550L J 250 A Inverse time 250 A
SJ700B -750L J 300 A Inverse time 300 A
Model No. Fuse Size (Maximum A) Circuit Breaker (Maximum A)
Type
Rating Type Rating
SJ700B-055H
SJ700B-075H
SJ700B-110H
J
J
J
15A
20A
30 A
Inverse time
Inverse time
Inverse time
15A
20A
30 A
SJ700B-150H J 40 A Inverse time 40 A
SJ700B-185H J 50 A Inverse time 50 A
SJ700B-220H J 50 A Inverse time 50 A
SJ700B-300H J 75 A Inverse time 75 A
SJ700B-370H J 80 A Inverse time 80 A
SJ700B-450H J 100 A Inverse time 100 A
SJ700B-550H J 125 A Inverse time 125 A
SJ700B-750H J 150 A Inverse time 150 A
SJ700B-900H J 225 A Inverse time 225 A
SJ700B-1100H J 225 A Inverse time 225 A
SJ700B-1320H J 300 A Inverse time 300 A
SJ700B-1600H J 350 A Inverse time 350 A
12. “Field wiring connection must be made by a UL Listed and CN closed-loop terminal connector sized for
the wire gauge being used. The connector must be fixed using the crimping tool specified by the
connector manufacturer.” or equivalent wording included in the manual.
13.“Motor over temperature protection is not provided by the drive.”
