Hitachi Virtual Storage Platform G130 User Manual

Chapter 1: Overview
The following describes hardware components, features, and congurations of the
Hitachi Virtual Storage Platform G130.
About Hitachi Virtual Storage Platform G130
The VSP G130 is comprised of a controller chassis and drive trays. The controller chassis
is equipped with a controller board, fans, dual power supply units, and drive bay for
small form-factor (SFF) or large form-factor (LFF) SAS disk drives. The controller board is
embedded with Fibre Channel interface, cache ash memory (CFM), and battery backup
modules.
The storage system supports small form-factor (DBS) and large form-factor (DBL) drive
trays. Both drive trays are equipped with an I/O module (ENC) and redundant power
supplies with integrated cooling fans. The DBS tray supports SFF SAS disk drives. The DBL
tray supports LFF SAS disk drives.
Features
■
Modular and versatile system congurations
■
High reliability and strong performance
■
Simple management of array
■
Easily expandable storage capacity
Scalability and versatility
■
One dual controller chassis with on-board SFF or LFF SAS disk drives
■
Host interfaces: 16-Gbps FC
■
One or more optional drive trays (up to three DBS drive trays or seven DBL drive
trays)
■
Optional service processor (SVP)
System configurations
The following table lists the supported system congurations with maximum mountable
drive tray and data drives for the VSP G130 storage system.
Chapter 1: Overview
Hitachi Virtual Storage Platform G130 Hardware Reference Guide 10
